Тензодатчик Zemic L6N-C3-8kg-3B6

Розничная цена
54 $ с НДС
array(34) { ["id"]=> string(6) "108287" ["product_id"]=> string(6) "171776" ["id_1c"]=> NULL ["sku"]=> string(0) "" ["sort"]=> string(1) "1" ["name"]=> string(0) "" ["image_id"]=> NULL ["price"]=> float(5150) ["primary_price"]=> string(7) "54.2089" ["purchase_price"]=> float(0) ["compare_price"]=> float(0) ["count"]=> float(0) ["available"]=> string(1) "1" ["stock_base_ratio"]=> NULL ["order_count_min"]=> NULL ["order_count_step"]=> NULL ["status"]=> string(1) "1" ["dimension_id"]=> NULL ["file_name"]=> string(0) "" ["file_size"]=> string(1) "0" ["file_description"]=> NULL ["virtual"]=> string(1) "0" ["ymleasyimport_price_id"]=> NULL ["id_xmlimport"]=> NULL ["stock"]=> array(3) { [1]=> float(0) [3]=> float(0) [4]=> float(0) } ["unconverted_currency"]=> string(3) "USD" ["currency"]=> string(3) "RUB" ["frontend_price"]=> float(5150) ["unconverted_price"]=> float(54.2) ["frontend_compare_price"]=> float(0) ["unconverted_compare_price"]=> float(0) ["original_price"]=> float(5150) ["original_compare_price"]=> float(0) ["features"]=> array(25) { ["tip1"]=> array(1) { [1420]=> string(41) "Балочный одноточечный" } ["nagruzka"]=> object(shopDimensionValue)#1154 (10) { ["id":"shopDimensionValue":private]=> string(5) "11258" ["value":"shopDimensionValue":private]=> string(1) "8" ["unit":"shopDimensionValue":private]=> string(2) "kg" ["type":"shopDimensionValue":private]=> string(6) "weight" ["units":"shopDimensionValue":private]=> array(6) { ["t"]=> array(3) { ["value"]=> string(1) "t" ["title"]=> string(2) "т" ["description"]=> NULL } ["kg"]=> array(3) { ["value"]=> string(2) "kg" ["title"]=> string(4) "кг" ["description"]=> NULL } ["g"]=> array(3) { ["value"]=> string(1) "g" ["title"]=> string(2) "г" ["description"]=> NULL } ["mg"]=> array(3) { ["value"]=> string(2) "mg" ["title"]=> string(4) "мг" ["description"]=> NULL } ["lbs"]=> array(3) { ["value"]=> string(3) "lbs" ["title"]=> string(8) "фунт" ["description"]=> NULL } ["oz"]=> array(3) { ["value"]=> string(2) "oz" ["title"]=> string(10) "унция" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> string(1) "8" ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(4) "кг" ["format":"shopDimensionValue":private]=> bool(false) } ["brend"]=> array(1) { [1431]=> string(5) "Zemic" } ["klass_tochnosti"]=> string(2) "C3" ["pogreshnost"]=> object(shopRangeValue)#1171 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1172 (10) { ["id":"shopDimensionValue":private]=> string(2) "68" ["value":"shopDimensionValue":private]=> string(5) "-0.02" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1173 (10) { ["id":"shopDimensionValue":private]=> string(2) "68" ["value":"shopDimensionValue":private]=> string(4) "0.02" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(2) "FS" ["type":"shopRangeValue":private]=> string(9) "fullscale" ["begin_base_unit":"shopRangeValue":private]=> string(5) "-0.02" ["end_base_unit":"shopRangeValue":private]=> string(4) "0.02" } ["maksimalnoe_kolichestvo_poverochnykh_intervalov_nmax"]=> string(4) "3000" ["minimalnyy_poverochnyy_interval_vmin"]=> string(9) "Emax/7000" ["material"]=> array(1) { [1823]=> string(33) "Алюминиевый сплав" } ["klass_zashchity"]=> string(4) "IP65" ["napryazhenie_pitaniya_dc"]=> object(shopRangeValue)#1162 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1163 (10) { ["id":"shopDimensionValue":private]=> string(3) "117" ["value":"shopDimensionValue":private]=> string(1) "5" ["unit":"shopDimensionValue":private]=> string(1) "V" ["type":"shopDimensionValue":private]=> string(12) "napryazhenie" ["units":"shopDimensionValue":private]=> array(5) { ["µV"]=> array(3) { ["value"]=> string(3) "µV" ["title"]=> string(6) "мкВ" ["description"]=> NULL } ["mV"]=> array(3) { ["value"]=> string(2) "mV" ["title"]=> string(4) "мВ" ["description"]=> NULL } ["V"]=> array(3) { ["value"]=> string(1) "V" ["title"]=> string(2) "В" ["description"]=> NULL } ["KV"]=> array(3) { ["value"]=> string(2) "KV" ["title"]=> string(2) "KV" ["description"]=> NULL } ["MV"]=> array(3) { ["value"]=> string(2) "MV" ["title"]=> string(4) "МВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(2) "В" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1164 (10) { ["id":"shopDimensionValue":private]=> string(3) "117" ["value":"shopDimensionValue":private]=> string(2) "12" ["unit":"shopDimensionValue":private]=> string(1) "V" ["type":"shopDimensionValue":private]=> string(12) "napryazhenie" ["units":"shopDimensionValue":private]=> array(5) { ["µV"]=> array(3) { ["value"]=> string(3) "µV" ["title"]=> string(6) "мкВ" ["description"]=> NULL } ["mV"]=> array(3) { ["value"]=> string(2) "mV" ["title"]=> string(4) "мВ" ["description"]=> NULL } ["V"]=> array(3) { ["value"]=> string(1) "V" ["title"]=> string(2) "В" ["description"]=> NULL } ["KV"]=> array(3) { ["value"]=> string(2) "KV" ["title"]=> string(2) "KV" ["description"]=> NULL } ["MV"]=> array(3) { ["value"]=> string(2) "MV" ["title"]=> string(4) "МВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(2) "В" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(1) "V" ["type":"shopRangeValue":private]=> string(12) "napryazhenie" ["begin_base_unit":"shopRangeValue":private]=> string(1) "5" ["end_base_unit":"shopRangeValue":private]=> string(2) "12" } ["maksimalnoe_napryazhenie_pitaniya_dc"]=> object(shopDimensionValue)#1148 (10) { ["id":"shopDimensionValue":private]=> string(5) "11295" ["value":"shopDimensionValue":private]=> string(2) "18" ["unit":"shopDimensionValue":private]=> string(1) "V" ["type":"shopDimensionValue":private]=> string(12) "napryazhenie" ["units":"shopDimensionValue":private]=> array(5) { ["µV"]=> array(3) { ["value"]=> string(3) "µV" ["title"]=> string(6) "мкВ" ["description"]=> NULL } ["mV"]=> array(3) { ["value"]=> string(2) "mV" ["title"]=> string(4) "мВ" ["description"]=> NULL } ["V"]=> array(3) { ["value"]=> string(1) "V" ["title"]=> string(2) "В" ["description"]=> NULL } ["KV"]=> array(3) { ["value"]=> string(2) "KV" ["title"]=> string(2) "KV" ["description"]=> NULL } ["MV"]=> array(3) { ["value"]=> string(2) "MV" ["title"]=> string(4) "МВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> string(2) "18" ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(2) "В" ["format":"shopDimensionValue":private]=> bool(false) } ["soprotivlenie_izolyatsii"]=> object(shopDimensionValue)#1090 (10) { ["id":"shopDimensionValue":private]=> string(5) "11218" ["value":"shopDimensionValue":private]=> string(4) "5000" ["unit":"shopDimensionValue":private]=> string(4) "Mohm" ["type":"shopDimensionValue":private]=> string(10) "resistance" ["units":"shopDimensionValue":private]=> array(3) { ["ohm"]=> array(3) { ["value"]=> string(3) "ohm" ["title"]=> string(4) "Ом" ["description"]=> NULL } ["kohm"]=> array(3) { ["value"]=> string(4) "kohm" ["title"]=> string(6) "кОм" ["description"]=> NULL } ["Mohm"]=> array(3) { ["value"]=> string(4) "Mohm" ["title"]=> string(6) "МОм" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> string(10) "5000000000" ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(6) "МОм" ["format":"shopDimensionValue":private]=> bool(false) } ["vkhodnoe_soprotivlenie"]=> object(shopRangeValue)#1186 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1187 (10) { ["id":"shopDimensionValue":private]=> string(3) "418" ["value":"shopDimensionValue":private]=> string(3) "388" ["unit":"shopDimensionValue":private]=> string(3) "ohm" ["type":"shopDimensionValue":private]=> string(10) "resistance" ["units":"shopDimensionValue":private]=> array(3) { ["ohm"]=> array(3) { ["value"]=> string(3) "ohm" ["title"]=> string(4) "Ом" ["description"]=> NULL } ["kohm"]=> array(3) { ["value"]=> string(4) "kohm" ["title"]=> string(6) "кОм" ["description"]=> NULL } ["Mohm"]=> array(3) { ["value"]=> string(4) "Mohm" ["title"]=> string(6) "МОм" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(4) "Ом" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1188 (10) { ["id":"shopDimensionValue":private]=> string(3) "418" ["value":"shopDimensionValue":private]=> string(3) "400" ["unit":"shopDimensionValue":private]=> string(3) "ohm" ["type":"shopDimensionValue":private]=> string(10) "resistance" ["units":"shopDimensionValue":private]=> array(3) { ["ohm"]=> array(3) { ["value"]=> string(3) "ohm" ["title"]=> string(4) "Ом" ["description"]=> NULL } ["kohm"]=> array(3) { ["value"]=> string(4) "kohm" ["title"]=> string(6) "кОм" ["description"]=> NULL } ["Mohm"]=> array(3) { ["value"]=> string(4) "Mohm" ["title"]=> string(6) "МОм" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(4) "Ом" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(3) "ohm" ["type":"shopRangeValue":private]=> string(10) "resistance" ["begin_base_unit":"shopRangeValue":private]=> string(3) "388" ["end_base_unit":"shopRangeValue":private]=> string(3) "400" } ["vykhodnoe_soprotivlenie"]=> object(shopRangeValue)#1165 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1166 (10) { ["id":"shopDimensionValue":private]=> string(2) "78" ["value":"shopDimensionValue":private]=> string(3) "347" ["unit":"shopDimensionValue":private]=> string(3) "ohm" ["type":"shopDimensionValue":private]=> string(10) "resistance" ["units":"shopDimensionValue":private]=> array(3) { ["ohm"]=> array(3) { ["value"]=> string(3) "ohm" ["title"]=> string(4) "Ом" ["description"]=> NULL } ["kohm"]=> array(3) { ["value"]=> string(4) "kohm" ["title"]=> string(6) "кОм" ["description"]=> NULL } ["Mohm"]=> array(3) { ["value"]=> string(4) "Mohm" ["title"]=> string(6) "МОм" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(4) "Ом" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1167 (10) { ["id":"shopDimensionValue":private]=> string(2) "78" ["value":"shopDimensionValue":private]=> string(3) "353" ["unit":"shopDimensionValue":private]=> string(3) "ohm" ["type":"shopDimensionValue":private]=> string(10) "resistance" ["units":"shopDimensionValue":private]=> array(3) { ["ohm"]=> array(3) { ["value"]=> string(3) "ohm" ["title"]=> string(4) "Ом" ["description"]=> NULL } ["kohm"]=> array(3) { ["value"]=> string(4) "kohm" ["title"]=> string(6) "кОм" ["description"]=> NULL } ["Mohm"]=> array(3) { ["value"]=> string(4) "Mohm" ["title"]=> string(6) "МОм" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(4) "Ом" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(3) "ohm" ["type":"shopRangeValue":private]=> string(10) "resistance" ["begin_base_unit":"shopRangeValue":private]=> string(3) "347" ["end_base_unit":"shopRangeValue":private]=> string(3) "353" } ["rabochiy_diapazon_temperatur"]=> object(shopRangeValue)#1168 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1169 (10) { ["id":"shopDimensionValue":private]=> string(3) "120" ["value":"shopDimensionValue":private]=> string(3) "-35" ["unit":"shopDimensionValue":private]=> string(3) "°C" ["type":"shopDimensionValue":private]=> string(11) "temperature" ["units":"shopDimensionValue":private]=> array(3) { ["°C"]=> array(3) { ["value"]=> string(3) "°C" ["title"]=> string(3) "°C" ["description"]=> NULL } ["K"]=> array(3) { ["value"]=> string(1) "K" ["title"]=> string(1) "K" ["description"]=> NULL } ["°F"]=> array(3) { ["value"]=> string(3) "°F" ["title"]=> string(3) "°F" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(3) "°C" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1170 (10) { ["id":"shopDimensionValue":private]=> string(3) "120" ["value":"shopDimensionValue":private]=> string(2) "70" ["unit":"shopDimensionValue":private]=> string(3) "°C" ["type":"shopDimensionValue":private]=> string(11) "temperature" ["units":"shopDimensionValue":private]=> array(3) { ["°C"]=> array(3) { ["value"]=> string(3) "°C" ["title"]=> string(3) "°C" ["description"]=> NULL } ["K"]=> array(3) { ["value"]=> string(1) "K" ["title"]=> string(1) "K" ["description"]=> NULL } ["°F"]=> array(3) { ["value"]=> string(3) "°F" ["title"]=> string(3) "°F" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(3) "°C" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(3) "°C" ["type":"shopRangeValue":private]=> string(11) "temperature" ["begin_base_unit":"shopRangeValue":private]=> string(3) "-35" ["end_base_unit":"shopRangeValue":private]=> string(2) "70" } ["predel_dopustimoy_nagruzki_elim"]=> object(shopDimensionValue)#1151 (10) { ["id":"shopDimensionValue":private]=> string(5) "11256" ["value":"shopDimensionValue":private]=> string(3) "150" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(4) "elim" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> string(3) "150" ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["razrushayushchaya_nagruzka"]=> object(shopDimensionValue)#1153 (10) { ["id":"shopDimensionValue":private]=> string(5) "11296" ["value":"shopDimensionValue":private]=> string(3) "300" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> string(3) "300" ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["chuvstvitelnost"]=> object(shopRangeValue)#1174 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1175 (10) { ["id":"shopDimensionValue":private]=> string(2) "79" ["value":"shopDimensionValue":private]=> string(3) "1.8" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(11) "sensitivity" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(7) "мВ/В" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(7) "мВ/В" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1176 (10) { ["id":"shopDimensionValue":private]=> string(2) "79" ["value":"shopDimensionValue":private]=> string(3) "2.2" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(11) "sensitivity" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(7) "мВ/В" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(7) "мВ/В" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(2) "FS" ["type":"shopRangeValue":private]=> string(11) "sensitivity" ["begin_base_unit":"shopRangeValue":private]=> string(6) "0.0018" ["end_base_unit":"shopRangeValue":private]=> string(6) "0.0022" } ["balans_nulya"]=> object(shopRangeValue)#1177 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1178 (10) { ["id":"shopDimensionValue":private]=> string(3) "415" ["value":"shopDimensionValue":private]=> string(1) "2" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1179 (10) { ["id":"shopDimensionValue":private]=> string(3) "415" ["value":"shopDimensionValue":private]=> string(1) "2" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(2) "FS" ["type":"shopRangeValue":private]=> string(9) "fullscale" ["begin_base_unit":"shopRangeValue":private]=> string(1) "2" ["end_base_unit":"shopRangeValue":private]=> string(1) "2" } ["temperaturnoe_otkloneniya_nulya"]=> object(shopRangeValue)#1157 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1160 (10) { ["id":"shopDimensionValue":private]=> string(2) "36" ["value":"shopDimensionValue":private]=> string(5) "-0.02" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(13) "fullscaletemp" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(14) "% НПВ/10°C" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(14) "% НПВ/10°C" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1161 (10) { ["id":"shopDimensionValue":private]=> string(2) "36" ["value":"shopDimensionValue":private]=> string(4) "0.02" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(13) "fullscaletemp" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(14) "% НПВ/10°C" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(14) "% НПВ/10°C" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(2) "FS" ["type":"shopRangeValue":private]=> string(13) "fullscaletemp" ["begin_base_unit":"shopRangeValue":private]=> string(5) "-0.02" ["end_base_unit":"shopRangeValue":private]=> string(4) "0.02" } ["temperaturnoe_otklonenie_chuvstvitelnosti"]=> object(shopRangeValue)#1180 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1181 (10) { ["id":"shopDimensionValue":private]=> string(3) "411" ["value":"shopDimensionValue":private]=> string(7) "-0.0175" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(13) "fullscaletemp" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(14) "% НПВ/10°C" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(14) "% НПВ/10°C" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1182 (10) { ["id":"shopDimensionValue":private]=> string(3) "411" ["value":"shopDimensionValue":private]=> string(6) "0.0175" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(13) "fullscaletemp" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(14) "% НПВ/10°C" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(14) "% НПВ/10°C" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(2) "FS" ["type":"shopRangeValue":private]=> string(13) "fullscaletemp" ["begin_base_unit":"shopRangeValue":private]=> string(7) "-0.0175" ["end_base_unit":"shopRangeValue":private]=> string(6) "0.0175" } ["diapazon_termokompensatsii"]=> object(shopRangeValue)#1158 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1159 (10) { ["id":"shopDimensionValue":private]=> string(3) "184" ["value":"shopDimensionValue":private]=> string(3) "-10" ["unit":"shopDimensionValue":private]=> string(3) "°C" ["type":"shopDimensionValue":private]=> string(11) "temperature" ["units":"shopDimensionValue":private]=> array(3) { ["°C"]=> array(3) { ["value"]=> string(3) "°C" ["title"]=> string(3) "°C" ["description"]=> NULL } ["K"]=> array(3) { ["value"]=> string(1) "K" ["title"]=> string(1) "K" ["description"]=> NULL } ["°F"]=> array(3) { ["value"]=> string(3) "°F" ["title"]=> string(3) "°F" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(3) "°C" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1156 (10) { ["id":"shopDimensionValue":private]=> string(3) "184" ["value":"shopDimensionValue":private]=> string(2) "40" ["unit":"shopDimensionValue":private]=> string(3) "°C" ["type":"shopDimensionValue":private]=> string(11) "temperature" ["units":"shopDimensionValue":private]=> array(3) { ["°C"]=> array(3) { ["value"]=> string(3) "°C" ["title"]=> string(3) "°C" ["description"]=> NULL } ["K"]=> array(3) { ["value"]=> string(1) "K" ["title"]=> string(1) "K" ["description"]=> NULL } ["°F"]=> array(3) { ["value"]=> string(3) "°F" ["title"]=> string(3) "°F" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(3) "°C" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(3) "°C" ["type":"shopRangeValue":private]=> string(11) "temperature" ["begin_base_unit":"shopRangeValue":private]=> string(3) "-10" ["end_base_unit":"shopRangeValue":private]=> string(2) "40" } ["polzuchest_30_min"]=> object(shopRangeValue)#1183 (6) { ["begin":"shopRangeValue":private]=> object(shopDimensionValue)#1184 (10) { ["id":"shopDimensionValue":private]=> string(3) "412" ["value":"shopDimensionValue":private]=> string(7) "-0.0167" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["end":"shopRangeValue":private]=> object(shopDimensionValue)#1185 (10) { ["id":"shopDimensionValue":private]=> string(3) "412" ["value":"shopDimensionValue":private]=> string(6) "0.0167" ["unit":"shopDimensionValue":private]=> string(2) "FS" ["type":"shopDimensionValue":private]=> string(9) "fullscale" ["units":"shopDimensionValue":private]=> array(1) { ["FS"]=> array(3) { ["value"]=> string(2) "FS" ["title"]=> string(8) "% НПВ" ["description"]=> NULL } } ["selected":"shopDimensionValue":private]=> bool(false) ["value_base_unit":"shopDimensionValue":private]=> NULL ["base_code":"shopDimensionValue":private]=> NULL ["unit_name":"shopDimensionValue":private]=> string(8) "% НПВ" ["format":"shopDimensionValue":private]=> bool(false) } ["unit":"shopRangeValue":private]=> string(2) "FS" ["type":"shopRangeValue":private]=> string(9) "fullscale" ["begin_base_unit":"shopRangeValue":private]=> string(7) "-0.0167" ["end_base_unit":"shopRangeValue":private]=> string(6) "0.0167" } ["tip_zapchasti"]=> array(1) { [1412]=> string(22) "Тензодатчик" } ["strana"]=> string(10) "Китай" } }
5 150 с НДС
Последнее обновление цены:
-
+
Купить в 1 клик
Скидки от суммы заказа
Гарантия от производителя
Ходовые товары на складе
Наличный и безналичный расчет
Доставка по России и СНГ
Добавлено в корзину!

Товаров: 0

На сумму: 0

Продолжить покупки
Оформить заказ
Описание
Оплата
Доставка
Гарантия
Инструкции

Описание товара

Тензометрический датчик веса одноточечный Zemic L6N-C3-8kg-3B6 предназначен для настольных и платформенных весов малой грузоподъемности, фасовочного и дозировочного оборудования, почтовых и торговых систем. Конструкция одноточечного типа обеспечивает устойчивую работу при эксцентриковой нагрузке, поэтому показания остаются стабильными даже при смещении груза на площадке. Алюминиевый сплав и степень защиты IP65 помогают работать в запыленных помещениях и при периодической влажной уборке, при этом важно соблюдение правил монтажа и ухода.

Датчик Zemic L6N-C3-8kg-3B6 относится к высокоточному классу C3 и хорошо подходит для задач, где требуются повторяемость измерений и быстрая стабилизация показаний. Для надежной эксплуатации важны ровное основание, корректная ориентация датчика, отсутствие боковых и крутящих усилий, а также правильная организация кабельного ввода с разгрузкой от натяжения.

Типичные причины поломок

  • Перегрузка и ударные нагрузки: падение тяжелого предмета на платформу, рывки, сильные вибрации.
  • Неправильный монтаж: перекос платформы, боковое усилие, жесткое зажатие без компенсации температурных деформаций.
  • Попадание влаги через поврежденный кабель или негерметичные узлы, длительная конденсация внутри корпуса.
  • Механические повреждения кабеля: перегиб на выходе, натяжение, защемление, перетирание.
  • Коррозионное воздействие моющих и химических средств при отсутствии защиты.
  • Электрические воздействия: статика, импульсные помехи, сварочные работы рядом с подключенным датчиком.
  • Засорение и трение элементов платформы об ограничители/корпус, создающее паразитные силы.

Как понять, что запчасть вышла из строя

  • Сильный уход нуля без нагрузки, требующий частой корректировки, либо невозможность установить ноль.
  • Нестабильные показания: дрожание, длительная стабилизация, «плавание» результата при неизменном грузе.
  • Плохая повторяемость: разный результат при неоднократном взвешивании одного и того же груза.
  • Нарушение одноточечности: заметная разница показаний при перемещении груза по углам и центру платформы.
  • Явные механические дефекты: вмятины, трещины, следы коррозии, поврежденная изоляция кабеля.
  • Проблемы с подключением: обрыв или короткое замыкание в проводах при проверке тестером.
  • Несоответствие эталонным грузам после корректной калибровки.

Рекомендации по уходу и эксплуатации

  • Предусмотреть механические ограничители и демпфирование, чтобы исключить перегрузки и удары.
  • Монтировать Zemic L6N-C3-8kg-3B6 на жесткое ровное основание, без перекоса; затяжку крепежа выполнять равномерно.
  • Избегать боковых усилий и заклинивания платформы; обеспечить свободный ход без трения и зазоров, мешающих вертикальной деформации.
  • Защищать кабель: использовать гофру или ввод с разгрузкой, избегать острых изгибов и натяжения, не допускать его вращения при работе.
  • Поддерживать чистоту: удалять пыль и остатки продукции вокруг подвижных узлов, чтобы исключить паразитные силы.
  • При влажной уборке не направлять струю воды на выход кабеля и места соединений; после мойки обеспечивать просушку.
  • Не проводить сварочные работы рядом с подключенным датчиком; применять заземление и экранирование, учитывать прокладку сигнального кабеля вдали от силовых линий.
  • Избегать длительной эксплуатации вне рекомендуемого температурного диапазона; по возможности обеспечивать термостабильность.
  • Периодически осматривать корпус и кабель, проверять крепеж; при первых признаках отказа проводить диагностику и калибровку.
  • Использовать корректные методы калибровки с эталонными грузами и проверку одноточечности по углам платформы.

При соблюдении этих рекомендаций одноточечный датчик Zemic L6N-C3-8kg-3B6 обеспечивает стабильную работу в системах взвешивания малых весов. Если после калибровки сохраняются значительные дрейфы, отсутствует повторяемость или обнаружены механические повреждения, целесообразна замена датчика, так как восстановление точности в таких случаях затруднено.

Характеристики

Тип тензодатчика Балочный одноточечный
Нагрузка (НПВ) 8 кг
Производитель Zemic
Класс точности C3
Погрешность -0.02 — 0.02 % НПВ
Максимальное количество поверочных интервалов (Nmax) 3000
Минимальный поверочный интервал (Vmin) Emax/7000
Материал Алюминиевый сплав
Класс защиты IP65
Напряжение питания DC 5 — 12 В
Максимальное напряжение питания DC 18 В
Сопротивление изоляции 5000 МОм
Входное сопротивление 388 — 400 Ом
Выходное сопротивление 347 — 353 Ом
Рабочий диапазон температур -35 — 70 °C
Предел допустимой нагрузки (Elim) 150 % НПВ
Разрушающая нагрузка 300 % НПВ
Чувствительность 1.8 — 2.2 мВ/В
Баланс нуля 2 — 2 % НПВ
Температурное отклонения нуля -0.02 — 0.02 % НПВ/10°C
Температурное отклонение чувствительности -0.0175 — 0.0175 % НПВ/10°C
Диапазон термокомпенсации -10 — 40 °C
Ползучесть (30 мин) -0.0167 — 0.0167 % НПВ
Тип запчасти Тензодатчик
Страна производства Китай



Важная информация

Все информационные материалы, представленные на сайте, носят справочный характер и не могут в полной мере передавать достоверную информацию о свойствах и характеристиках Тензодатчик Zemic L6N-C3-8kg-3B6.

Фотография на сайте служит дополнительным источником для определения совместимости запчастей с Вашим оборудованием, и не может являться основным. Основной источник по совместимости запчастей - актуальная документация производителя оборудования, из которой значимой информацией для заказа являются: название запчасти и каталожный номер.

Запасные части и комплектующие подбираются самостоятельно покупателем строго по каталожным номерам из официальных деталировок производителей. В случае, если номенклатура товара совпадает с фактически поставленной, но не подходит на оборудование - в ее замене или возврате может быть отказано.

Цена Тензодатчик Zemic L6N-C3-8kg-3B6 на сайте имеет информационный характер и может отличаться от цены в коммерческом предложении.
