| System components | ||
|---|---|---|
| Emitter | SLP30-3-T | |
| Receiver | SLPC30-3-R | |
| General specifications | ||
| Effective detection range | 6 ... 30 m | |
| Light source | LED | |
| Light type | modulated visible red light | |
| Safety type according to IEC/EN 61496 | 4 | |
| Marking | CE | |
| Target size | static: 32 mm dynamic: 50 mm (at v = 1.6 m/s of the obstacle) | |
| Beam spacing | 400 mm | |
| Number of beams | 3 | |
| Operating mode | Start/restart disable, relay monitor, | |
| Angle of divergence | < 5 ° | |
| Functional safety related parameters | ||
| Safety Integrity Level (SIL) | SIL 3 | |
| Performance level (PL) | PL e | |
| Category | Cat. 4 | |
| Mission Time (TM) | 20 a | |
| PFHd | 3.54 E-9 | |
| Indicators/operating means | ||
| Diagnostics indicator | 7-segment display | |
| Function indicator | LED red: per receiver channel off: interruption flashes: receiver continuously on: reception with sufficient stability control on the front plate: LED red: OSSD off LED green: OSSD on | |
| Pre-fault indicator | LED red next to receiver flashes | |
| Electrical specifications | ||
| Operating voltage | 24 V DC -15% / +25% , galvanically isolated | |
| Input | ||
| Function input | Relay monitor, start release | |
| Output | ||
| Safety output | 2 separated fail safe semiconductor outputs | |
| Signal output | 1 PNP each, max. 300 mA for start readiness, OSSD on, OSSD off | |
| Switching voltage | Operating voltage -2 V | |
| Switching current | max. 0.5 A | |
| Mechanical specifications | ||
| Degree of protection | IP65 | |
| Connection | M16 cable gland , terminal compartment with cage-terminals, M12-connector for emitter | |
| Производитель | Pepperl+Fuchs |
Все информационные материалы, представленные на сайте, носят справочный характер и не могут в полной мере передавать достоверную информацию о свойствах и характеристиках Интерфейсный модуль безопасности Safety light grid with integrated control unit SLPC30-3 Pepperl+Fuchs.
Фотография на сайте служит дополнительным источником для определения совместимости запчастей с Вашим оборудованием, и не может являться основным. Основной источник по совместимости запчастей - актуальная документация производителя оборудования, из которой значимой информацией для заказа являются: название запчасти и каталожный номер.
Запасные части и комплектующие подбираются самостоятельно покупателем строго по каталожным номерам из официальных деталировок производителей. В случае, если номенклатура товара совпадает с фактически поставленной, но не подходит на оборудование - в ее замене или возврате может быть отказано.
Цена Интерфейсный модуль безопасности Safety light grid with integrated control unit SLPC30-3 Pepperl+Fuchs на сайте имеет информационный характер и может отличаться от цены в коммерческом предложении.
