Индуктивный датчик NMB10-18GM55-E2 Pepperl+Fuchs предназначен для бесконтактного обнаружения металлических объектов в автоматизированных системах. Он применяется в линиях розлива и упаковки, на конвейерах, в транспортёрах, сборочных приспособлениях, а также в пищевой и машиностроительной отрасли, где требуются стабильность срабатывания и высокая стойкость к внешним воздействиям. Конструкция рассчитана на встроенный (заподлицо) монтаж, что упрощает интеграцию в стандартные резьбовые посадочные места и защищает чувствительную поверхность от механических воздействий.
Корпус и лицевая поверхность выполнены из нержавеющей стали, что повышает устойчивость к моющим средствам, влаге и мелкой абразивной стружке. Прочный кабель из PUR хорошо переносит изгибы и воздействие масел, а светодиодные индикаторы питания и состояния упрощают диагностику на месте. Тип выхода — PNP с нормально разомкнутой логикой, что совместимо с подавляющим большинством входов ПЛК и модулей дискретного ввода.
Датчик уверенно работает с ферромагнитными и неферромагнитными объектами. При этом для разных материалов характерны свои коэффициенты снижения расстояния срабатывания: для стали — максимальная дальность, для алюминия и меди — ниже. Это важно учитывать при выборе формы и размеров мишени, а также при выставлении монтажного зазора.
Рекомендации по установке включают точное соблюдение требований для заподлицо-монтажа (минимальные отступы от металлоконструкций), надёжную фиксацию в резьбовой гильзе, разгрузку кабеля от натяжения и грамотное экранирование линии вблизи источников помех. Подключение выполняется к источнику постоянного напряжения и входу контроллера согласно типовой схеме для PNP NO. Желательно предусматривать защиту от импульсных перенапряжений и корректное заземление шкафа управления.
Типовые причины неисправностей
Как понять, что датчик вышел из строя
Рекомендации по уходу и профилактике
| Общие характеристики | ||
|---|---|---|
| Функция переключения | Нормально разомкнутый (NO) | |
| Тип выхода | PNP | |
| Номинальное расстояние срабатывания | 10 мм | |
| Установка | заподлицо (требования: см. чертёж ниже) | |
| Полярность выхода | Постоянный ток (DC) | |
| Гарантированное расстояние срабатывания | 0... 8,1 мм | |
| Объект срабатывания | Ферромагнитные и неферромагнитные цели | |
| Коэффициент снижения rAl | 0,4 | |
| Коэффициент снижения rCu | 0,25 | |
| Коэффициент снижения r304 | 0,85 | |
| Коэффициент снижения rSt37 | 1 | |
| Номинальные параметры | ||
| Рабочее напряжение | 10... 30 В DC | |
| Частота переключения | 0... 240 Гц | |
| Гистерезис | 3... 15, типично 10 % | |
| Защита от переполюсовки | есть | |
| Защита от короткого замыкания | импульсная | |
| Падение напряжения | ≤ 2 В | |
| Рабочий ток | ≤ 200 мА | |
| Ток в выключенном состоянии | 10 мкА | |
| Ток потребления без нагрузки | ≤ 10 мА | |
| Индикатор питания | Светодиод, зелёный | |
| Индикатор состояния переключения | Светодиод, жёлтый | |
| Параметры функциональной безопасности | ||
| MTTFd | 847 лет | |
| Время миссии (TM) | 20 лет | |
| Диагностическое покрытие (DC) | 0 % | |
| Одобрения и сертификаты | ||
| UL | cULus Listed, General Purpose | |
| CSA | cCSAus Listed, General Purpose | |
| CCC | Одобрение/маркировка CCC не требуются для изделий с напряжением ≤ 36 В | |
| Условия окружающей среды | ||
| Температура окружающей среды | -25... 70 °C (-13... 158 °F) | |
| Механические характеристики | ||
| Тип подключения | кабель PUR, 2 м | |
| Сечение жил | 0,5 мм2 | |
| Материал корпуса | Нержавеющая сталь 1.4305 / AISI 303 | |
| Лицевая поверхность | Нержавеющая сталь 1.4305 / AISI 303 | |
| Диаметр корпуса | 18 мм | |
| Степень защиты | IP69K | |
| Производитель | Pepperl+Fuchs |
